Key Features

• Space saving - With a width of the case being 8cm, this can be easily mounted on to the rear of your LCD / LED monitor using the VESA mount (provided), creating more desk space.


• Dual Layer Interior Structure - This case utilises its advanced dual layer interior, allowing for support of a slim ODD, HDD and 3 in 1 card reader.


• Supports i5 /i7 - Fully supports the Intel i5 and i7 CPUs, including the latest Haswell chipset.The mesh side panel offers better cooling.


• Internal PSU - Comes with an internal 180W power supply unit to better suit your needs.

  Specifications


  PSU Specifications:	Mini ITX PSU
  Connectors::	Per below info
  20+4 Pin ATX Motherboard:	1 (Cable Length: 300)
  4 Pin +12V CPU:	1 (Cable Length: 400 )
  SATA:	1 (Cable Length: 450 )
  FDD:	1 (Cable Length: 100 (from SATA))
  Dimensions :	(W) 55 x (H) 48 x (L) 170mm
  Input Voltage :	200 - 240V AC
  Input Current :	3A
  Input Frequency Range:	50 - 60Hz
  PFC:	No (APFC Optional at bronze)
  Power Good Signal:	100 - 500ms
  Hold Up Time:	10ms
  Efficiency :	≥ 82%(optional)
  M.T.B.F.:	100000 hrs
  Protection :	SCP / OPP / OVP / LVP
  Power :	130-180W Real (Optional)
  Max. Output:	180W

  Case Specifications


  Form Factor:	Mini ITX
  Motherboard Support:	Mini ITX
  PSU Support:	Flex
  Body Material:	0.5mm SECC Metal
  Front Bezel Material:	Plastic
  Side Panel:	Window / Vented
  External Bays:	1 x Slimline Optical
  Internal Bays:	1 x 2.5 Internal
  IO Ports:	2 x USB 2.0 1 x HD Audio 1 x Microphone
  CPU Cooler Maximum Height:	42mm
  Front Bezel Colour:	Black
  Body Colour:	Black
  System Cabinet Features:	Card Reader Supports SD/MMC, CF/MD, XD, TF, MS/M2 PSU uses a clover leaf mains cable
  PSU Included:	Yes
  Vesa Mountable:	Yes

  General Specifications


  Manufacturer Part Number:	S102
  EAN Number:	5055492411983
  Colour:	Black
  What's In The Box:	Case Stand
  Unit (Product) Dimensions (mm):	95mm x 245mm x 221mm (W x H x D)
  Packaging Dimensions (mm):	131mm x 285mm x 265mm (W x H x D)
  Net Weight (KGs):	2.3 KGs
  Gross Weight (KGs):	3.1 KGs
